Yamaha YZF-R3
 | |
| Manufacturer | Yamaha Motor Company |
|---|---|
| Also called | Yamaha R3 |
| Parent company | Yamaha Corporation |
| Production | 2015-present |
| Class | Sport bike |
| Engine | 321 cc (19.6 cu in) liquid-cooled 4-stroke 8-valve DOHC inline-twin |
| Bore / stroke | 68.0 mm × 44.1 mm (2.7 in × 1.7 in) |
| Compression ratio | 11.2:1 |
| Transmission | 6-speed constant mesh |
| Frame type | Steel diamond |
| Suspension |
Front: 41 mm Telescopic fork Rear: Swingarm |
| Brakes |
Front: Single 298 mm hydraulic disc Rear: Single 220 mm hydraulic disc |
| Tires |
Front: 110/70-17 Rear: 140/70-17 |
| Rake, trail | 25°, 95 mm (3.7 in) |
| Wheelbase | 1,380 mm (54 in) |
| Dimensions |
L: 2,090 mm (82 in) W: 720 mm (28 in) H: 1,135 mm (44.7 in) |
| Seat height | 780 mm (31 in) |
| Weight | 169 kg (373 lb) (wet) |
| Fuel capacity | 14.0 L (3.1 imp gal; 3.7 US gal) |
| Oil capacity | 2.4 L (2.5 US qt) |
| Related |
Yamaha MT-03/MT-25 Yamaha YZF-R25 |
The Yamaha YZF-R3 is a sport motorcycle manufactured by Yamaha since 2015. It is sold as the YZF-R25 with a 321 cc (19.6 cu in) DOHC inline twin-cylinder engine, as opposed to the typical 4 cylinder engines common in the "R" line. It has a downdraft fuel injection system, 11.2:1 compression and an all aluminum DiASil coated cylinder with forged aluminum pistons. Peak HP is at 10,750rpm. The suspension contains KYB shocks up front with a preload-adjustable rear shock to compensate for rider weight and cargo.
ABS
New for the 2017 model is an ABS (Anti-Lock Brake) system coupled to the hydraulically actuated 298mm front and 220mm rear floating disk brakes to increase the safety of the rider.
